Per-channel power output : Power figures from independent laboratory testing under controlled conditions.

• 2500 W into 2 ohms (EIAJ 8:32 burst, 1 kHz, 1% THD)
• 2350 W into 4 ohms (1 kHz continuous) 1% THD
• 2275 W into 4 ohms (100 Hz continuous) 1% THD
• 1250 W into 8 ohms (1 kHz continuous) 1% THD
• 1200 W into 8 ohms (100 Hz continuous) 1% THD

• Number of channels: 4
• Frequency response (@8 ohms): 20 Hz – 20 kHz, �±0.3 dB
• Slew rate: 50 V/μs
• THD+N: <0.3%
• IMD (SMPTE): <0.3%
• Signal-to-noise ratio: >105 dB
• Crosstalk: >75 dB
• Damping factor: >800 (8 ohms, 20 Hz–200 Hz)
• Input sensitivity: 1 V
• Input impedance: 20 kΩ (balanced), 10 kΩ (unbalanced)
• Voltage gain: 40 dB
• Protection: Automatic mute if clip limit exceeded for >2 seconds
• Efficiency: >85%
• Cooling: Forced-air, front-to-rear airflow
• Height: 1U
• Product dimensions: 483 × 44 × 375 mm (W×H×D)
• Packaged dimensions: 530 × 90 × 530 mm (W×H×D)
• Net weight: 10.5 kg
• Gross weight: 12.2 kg
